Main specification | Transport Dimension(L*W*H) | 6100×2365×3752 mm |
Overall Operating Weight | 8200KG | |
Ground clearance | 300 mm | |
Driving type | 4-wheel-driving (4X4) | |
Loader performance | Loader bucket capacity | 1.0 m3 |
Max. Dumping height | 2742 mm | |
Rated load capacity | 2500 kg | |
Breakout force | 38 kN | |
Total cycling time | 11.9 s | |
Backhoe performance | Excavator bucket capacity | 0.3 m3 |
Max. Digging depth | 4082 mm | |
Max. Dumping height | 3795 mm | |
Boom rotary angle | 190° | |
Engine | Model | YC4A105Z-T20 |
Air inlet type | Turbocharged | |
Cylinders | Inline,Direct injection,4x108x132mm | |
Rated power | 75 kW | |
Rated speed | 2200r/min | |
Torque convertor | Type | Single-stage Three Elements |
Max. Efficiency | 84.40% | |
Inlet Pressure | 1.3－1.5Mpa | |
Outlet Pressure | 0.25－0.3Mpa | |
Cooling Method | Oil-cooling Pressure Circulation | |
Gearbox type | Type | Fixed Shaft Power Transmission |
Gears | Two forward, Two reverse gears | |
Max.Speed | 28Km/h | |
Driving axles | Manufacturer | YUNYU |
Main Transmission Type | Double Reduction | |
Final Reducer | Single Stage Final Reducer | |
Rated load of axle | 8/18.5t | |
Tyres | Model | 14-17.5/19.5L-24 |
Pressure of Front wheel | 0.55Mpa | |
Pressure of Back Wheel | 0.223Mpa | |
Brake system | Service Brake | Air Over Oil Caliper Brake,External Type,Self-regulation,Self-balance |
Operation Power Implementing brake | ||
Manual Operation Power Terminating Brake | ||
Steering System | Type | Articulated hydraulic steering |
Steering angle | left or right 36±1° | |
Min. turning radius | 6581mm |
